Specialty Labels
Cryogenic Labels for Liquid Nitrogen – -196°C Direct Immersion for Biobanks
As a trusted supplier of cryogenic labels for liquid nitrogen, we produce premium labels engineered for direct immersion in LN₂ at -196°C. Our cryogenic labels maintain adhesion and legibility on cryo‑vials, frozen storage boxes, and freezer racks without cracking or delaminating – ensuring reliable sample tracking in biobanks and research laboratories.
Specifications
- Material
- Cryogenic‑grade PET / Vinyl / PI (customizable)
- Color
- White, pastel colors (for color‑coding), fluorescent
- Standard sizes
- Custom die‑cut to fit cryo‑vials (0.5ml, 2ml, 5ml), straws, boxes
- Core diameter
- 1 inch (for roll labels)
Detailed Specifications
Material | Cryogenic‑grade PET / Vinyl / PI (customizable) |
Color | White, pastel colors (for color‑coding), fluorescent |
Adhesive | Specialized low‑temperature acrylic / silicone |
Temperature range | -196°C to +80°C (-320°F to +176°F) |
Standard sizes | Custom die‑cut to fit cryo‑vials (0.5ml, 2ml, 5ml), straws, boxes |
Core diameter | 1 inch (for roll labels) |
Print compatibility | Thermal transfer (resin ribbon required) |
Ready‑to‑use sheets and rolls available. Custom barcodes (1D/2D) and pre‑printed text offered.
Key Features
- Direct liquid nitrogen immersion – Labels remain attached and legible after prolonged storage at -196°C (vapor or liquid phase).
- Ultra‑low freezer performance – Functional down to -150°C for mechanical freezers; no embrittlement or adhesive failure.
- Crack‑resistant construction – Specially formulated facestock does not shatter or delaminate during temperature cycling.
- Thaw‑resistant printing – Resin ribbon imprint withstands condensation, scraping, and brief room‑temperature handling.
- Adhesion to frozen surfaces – Can be applied to cold vials (down to -80°C) with pressure – no pre‑warming needed.
- Compatible with cryo‑markers – Optional over‑laminate for additional protection against cryo‑proof pens.
- Specialised cryogenic label manufacturer – Our cryogenic labels for liquid nitrogen are formulated with premium facestock and LN₂‑rated adhesives, coated on precision lines for consistent performance through extreme cold.
Applications
Use Liquid Nitrogen Label for:
- Biobanks & biorepositories – Long‑term identification of human or animal tissue samples, stem cells, and DNA libraries stored in LN₂.
- IVF & assisted reproduction – Labeling of embryos, oocytes, and sperm vials that must remain sterile and legible.
- Pharmaceutical R&D – Stability sample tracking in cryogenic freezers for drug development.
- Vaccine storage – Ultra‑low temperature labels for COVID‑19 mRNA vaccines, viral vectors, and other thermolabile biologics.
- Liquid nitrogen dewars – External labels for LN₂ containers that are repeatedly handled and exposed to extreme cold.
For general freezer storage (-20°C to -80°C) without LN₂ immersion, our PP Synthetic Paper label is a lower‑cost alternative.
Printer & Ribbon Compatibility
Recommended ribbons:
- Resin ribbon (high‑energy) – Mandatory for cryogenic labels. Wax/resin ribbons will become brittle and flake off.
Compatible printers:
Most industrial thermal transfer printers from Zebra, Honeywell, Sato, TSC, Citizen. Desktop printers may work with resin ribbon – test small batch first.
Printer settings suggestion:
- Darkness: 25–30%
- Speed: 2–3 inches per second (ips) for optimal transfer onto the cold‑optimized coating.
💡 Tip: For best adhesion, let the label rest at room temperature for 1–2 minutes after printing before applying to cold vials.
How to Choose the Right Cryogenic Label
As a specialist in cryogenic labels for liquid nitrogen, we understand that not all low‑temperature labels perform equally at -196°C. Our cryogenic labels are formulated with premium polyimide or cryo‑grade PET facestock and LN₂‑rated silicone adhesives, coated on precision lines to ensure consistent adhesion and readability through extreme cold storage.
1. Temperature rating
- -196°C (liquid phase) – For direct LN₂ immersion – requires PI facestock + LN₂‑rated silicone adhesive
- -150°C to -190°C (vapour phase) – Less demanding, but still requires cryogenic‑grade materials
- -80°C (ultra‑low freezers) – Cryo‑grade PET or PI – lower cost option available
2. Material selection
- Polyimide (PI) – Recommended for -196°C liquid phase; the only material proven for direct LN₂ immersion
- Cryo‑grade PET – Suitable for -80°C freezers; not recommended for liquid nitrogen
- Vinyl – Limited to -80°C; not for LN₂
3. Adhesive type
- Silicone‑based – Recommended for -196°C; remains flexible and maintains bond strength
- Specialised cryogenic acrylic – Suitable for -80°C; may fail at -196°C
4. Printer & ribbon settings
- Ribbon: Resin ribbon only (wax/resin will become brittle and flake)
- Darkness: 25–30%
- Speed: 2–3 inches per second (ips)
⚠️ Note: Always test a small batch with your specific vials, storage conditions, and freeze‑thaw cycles before full deployment.
Ordering & Sample Information
As a direct supplier of cryogenic labels for liquid nitrogen, we offer factory pricing and full batch traceability on every roll.
- MOQ: 50 rolls or 50 sheet pack for standard blank labels; custom die‑cut – MOQ 100 rolls.
- Free sample: 5–10 pieces available for testing. Requires resin ribbon – we can provide matching sample.
- Custom printing: Barcode, text, or logo – MOQ 1000 pcs.
- Lead time:
- Blank labels: 3–5 business days
- Custom printed: 10–15 business days
- Large volume (>500 rolls): 20–25 days
❄️ | Cryogenic Labels for Liquid Nitrogen – Tested at -196°C for biobank and research applications |
🏭 | Specialist Cryogenic Label Manufacturer – Direct factory pricing and quality control |
📦 | Batch Traceability – Every roll logged from coating to slitting |
✅ | DNase/RNase Free Options – Available for sensitive biological samples |
Ready to order or test?
