Thermal Transfer Ribbon
Colored Resin Ribbon – Durable Printing for Branded & Safety Labels
Premium colored resin thermal transfer ribbons in red, blue, white, and more. Withstand heat, chemicals, and abrasion. Ideal for branded labels, safety markings, and color-coded tracking.
Specifications
- Color
- Red, Blue, White, Green, Yellow, Orange, Silver, Gold, Custom
- Width
- 40mm, 50mm, 60mm, 70mm, 80mm, 90mm, 110mm
- Length
- 300m, 450m, 600m per roll
Colored Resin Ribbon – Durable Printing for Branded & Safety Labels
Premium colored resin thermal transfer ribbons for printing on synthetic labels (PET, PI, PP) that require resistance to heat, chemicals, and abrasion. Available in red, blue, white, green, and custom colors – ideal for brand logos, safety markings, and color-coded tracking systems.
Specifications
Item | Details |
|---|---|
Color | Red, Blue, White, Green, Yellow, Orange, Silver, Gold, Custom |
Width | 40mm, 50mm, 60mm, 70mm, 80mm, 90mm, 110mm |
Length | 300m, 450m, 600m per roll |
Core diameter | 1 inch (25.4mm) or 0.5 inch |
Coating side | Outside / Inside (printer dependent) |
Print density | High (≥1.6 OD for black; color density verified by colorimeter) |
Recommended printers | Zebra, Honeywell, Sato, TSC, Citizen |
Certifications | RoHS, REACH, Halogen‑free |
Custom colors and sizes available upon request. Color matching service offered for brand-specific shades.
Key Features
- ✅ Vibrant, durable colors – Red, blue, white, green, yellow, orange, silver, gold – and custom shades available.
- ✅ Extreme chemical resistance – Withstands acetone, MEK, toluene, alcohols, and acids – color stays vivid.
- ✅ High thermal stability – Prints remain legible and color-stable from -40°C up to +120°C.
- ✅ Superior abrasion & scratch resistance – Ideal for rough handling, outdoor use, and automated scanning.
- ✅ Excellent adhesion – Bonds permanently to PET, PI, PP, PE, and some metal/glass surfaces.
- ✅ High print definition – Supports fine text, small barcodes, logos, and color graphics.
- ✅ Color consistency – Batch-to-batch color verified by spectrophotometer.
- ✅ Long printhead life – Formulated to minimize wear on thermal printheads.
Applications
Use Colored Resin Ribbon for:
- Brand logos & product labels – Add brand colors to synthetic labels for premium appearance.
- Safety & warning markings – Red/orange for hazard labels, yellow for caution, blue for information.
- Color-coded asset tracking – Different colors for different asset types, locations, or departments.
- Retail & apparel tags – White resin ribbon for dark PET/PP tags; colored ribbons for decorative labeling.
- Electronics & PCB labels – Color-coded tracking labels that survive reflow soldering.
- Laboratory & cleanroom – Color-coded identification for different chemicals or sample types.
- GMP & healthcare – Color-coded labeling for different grades, batches, or status (e.g., quarantined, approved).
Printer & Ribbon Compatibility
Recommended label materials:
- Polyimide (PI) – Best for high‑temperature reflow + color durability.
- PET (white, silver, clear) – Excellent color reproduction and chemical resistance.
- PP (synthetic paper) – Good color brightness, suitable for flexible surfaces.
- PE (film) – Test recommended for adhesion and color transfer.
- Coated paper – Limited color durability; use for short‑term indoor applications only.
Compatible printers:
Most industrial thermal transfer printers from Zebra (ZT series, ZQ series), Honeywell (PD45, PM45), Sato (CL, GL), TSC (Alpha, MH), Citizen (CL series).
Printer settings suggestion:
- Darkness: 25–30% (higher than wax/resin; test for optimal color transfer)
- Speed: 2–4 inches per second (ips) for dense, consistent color
⚠️ Note: Colored resin ribbon requires higher print energy than black resin. Color density can vary with speed/darkness – always test on your specific printer and label combination.
How to Choose the Right Colored Resin Ribbon
1. Color selection
Color | Best for |
|---|---|
Red | Safety/hazard labels, brand accents, stop/warning |
Blue | Brand logos, information labels, cleanroom indicators |
White | Dark PET/PP labels, premium contrast, reverse printing |
Yellow | Caution/warning, highlight, outdoor visibility |
Green | Safety, environmental, organic branding |
Orange | Warning, brand, visibility |
Silver/Gold | Premium/metallic look, luxury packaging |
Custom | Exact brand color matching (PMS/RAL codes) |
2. Width & length selection
- Width: Ribbon must be slightly wider than the label (e.g., label 50mm → ribbon 60mm) to protect the printhead.
- Length: 300m for small/medium volume; 450m for standard industrial use; 600m for high‑volume automated printers.
- Core: 1 inch core for most industrial printers; 0.5 inch core for some desktop models.
3. Color matching service
- We can match Pantone (PMS), RAL, or custom brand colors.
- MOQ for custom colors: 20 rolls (standard colors: 5 rolls).
Ordering & Sample Information
- MOQ: 50 rolls for standard colors (red, blue, white, green, yellow, orange); 100 rolls for custom colors.
- Free sample: 10‑meter sample available for testing. Request with your printer model, label material, and preferred color.
- Custom colors: PMS/RAL matching – MOQ 100 rolls, lead time 15–20 days.
- Colored ribbon care: Store in original packaging at 20–25°C, away from direct sunlight – color fade can occur with prolonged UV exposure.
- Lead time:
- Stock colors: 2–3 business days
- Custom colors: 15–20 business days
- Large volume (>100 rolls): 20–25 days
